Overview

Fuse terminal with screw connection for protecting electrical circuits using a 5x20mm cartridge fuse. The terminal mounts on a TS 35 rail and provides two connections on one level.

General Data

Product type	Fuse terminal
Connection type	Screw connection
Colour	Dark beige
Mounting rail	TS 35
Mounting type	Snap-on

Electrical Data

Rated voltage	500V
Rated current	6.3A
Rated impulse withstand voltage	6kV
Pollution severity	3

Connection Data

Rated cross-section	6mm²
Clamping range	0.5..10mm²
Conductor range	AWG 20..8
Stripping length	12mm
Tightening torque	0.8..1.6Nm
Number of connections	2
Number of levels	1

Fuse Data

Cartridge fuse	5x20mm
Fuse holder	Pivoting
Maximum operating voltage	250VAC/DC

Dimensions

Width	7.9mm
Height	60mm
Depth	61mm
Depth including DIN rail	62mm

Material Data

Basic material	Wemid
Flammability rating	UL 94 V-0
RoHS status	Compliant without exemption

Operating Conditions

Ambient temperature	-50..75°C
Storage temperature	-25..55°C

Standards

IEC 60947-7-3, IEC 60947-7-1
