Pilt on illustreeriv
|
Kruvi-riviklemm WDK 2.5PE, 2-korrust, 2.5mm² 300A 400V, Weidmüller, koro Kood:
1036300000
€ 4,40
/tk
(€ 5,37 /tk KM-ga)
Tootja
:
|
Saadavus:
Laos
|
Kaal:
0.0183 kg/tk
|
Maht:
0 m3/tk
|
Hulgipakendi kogus:
100tk
|
|
|
|
Korrus-riviklemm WDK 2.5 PE Weidmüller, koro
 |
WDK 2.5:
The PE terminals are available in two designs: standard and compact (N),
with rated cross-section from 1.5 mm2 to 150 mm2 (e.g. 2.5 mm2 – WPE 2.5 or 4 mm2 – WPE 4N).
|
|
| |
Technical data:
|
| Dimensions and weights: |
Width: 5.1 mm
Height: 69.5 mm
Height of the lowest version: 63.5 mm
Depth: 62.5 mm
Weight: 18.1 g
Net weight: 17.62 g |
Temperatures:
|
|
Continuous operating temp., min.: |
- 50 °C |
|
Continuous operating temp., max.: |
120 °C |
Product information:
|
|
Descriptive text technical data: |
2.5 mm2 conductor with ferrule with plastic collar, with the collar optimised for diameter only (order No. 1333100000, QTY 500). |
|
Descriptive text accessories: |
Rail support protective insulation for installation of mounting rail "SH 2" order No. 0494920000 (QTY 10). |
Additional technical data:
|
|
Explosion-tested version: |
Yes |
|
Installation advice: |
Direct mounting |
|
Number of similar terminals: |
1 |
|
Open sides: |
right |
|
Type of mounting: |
Snap-on |
|
Version: |
Screw connection, for screwable cross-connection, One end without connector |
CSA ratings data:
|
|
Certificate No. (CSA): |
200039-1057876 |
|
Wire cross section max. (CSA): |
12 AWG |
|
Wire cross section min. (CSA): |
26 AWG |
Rated data:
|
|
Rated voltage: |
400 V |
|
Rated impulse withstand voltage: |
6 kV |
|
Standards: |
IEC 60947-7-2 |
|
Pollution severity: |
3 |
Material data:
|
|
Material: |
Wemid |
|
Colour: |
Yellow, Green |
|
UL 94 flammability rating: |
V-0 |
System specifications:
|
|
Product family : |
W-Series |
|
Type of connection: |
Screw connection |
|
Connection direction: |
top |
|
Number of levels: |
2 |
|
Number of connections: |
4 |
|
No. of clamping points per level: |
2 |
|
Levels cross-connected internally: |
Yes |
|
Mounting rail: |
TS 35 |
|
End cover plate required: |
Yes |
Classifications:
|
|
ETIM 3.0: |
EC000901 |
|
UNSPSC: |
30-21-18-11 |
|
eClass 5.1: |
27-14-03-05 |
|
eClass 6.2: |
27-14-03-05 |
|
eClass 7.1: |
27-14-03-05 |
|
Approvals:
|
 |
|
|
File description
|
File type
|
Download link
|
|
|
|
|
|
Product data sheet
|
PDF
|
Download link
|
|
|
|
|
