Pilt on illustreeriv
|
Kompaktkaitselüliti SGM3S-800H, 800A 3x415VAC 85kA, short-circuit protection 0.8..1In, overload protection 10In, incl. mounting screws, insul. shields, panel mount Kood:
SGM3S-800H-3800
€ 618,00
/tk
(€ 766,32 /tk KM-ga)
Tootja
:
|
Saadavus:
Laos
|
Kaal:
0.1234 kg/tk
|
|
|
|
|
|
Overview
Moulded Case Circuit Breaker SGM3S-800H, 800A 3x415VAC 85kA, short-circuit protection 0.8..1In, overload protection 10In, incl. mounting screws, insul. shields, panel mount, MaxGE.
Specifications
| Frame Size |
800A |
| Model |
SGM3S-800 |
| Number of poles |
3, 4 |
| Rated current In |
630A, 700A, 770A, 800A |
| Thermo-adjustable setting Ir |
0.8/0.9/1.0In |
| Standard |
IEC60947-2 |
| Reference temperature |
40℃/55℃ |
| Rated insulation voltage Ui |
800V |
| Rated impulse withstand voltage Uimp |
8kV |
| Fixed magnetic trip |
Yes |
Breaking Capacity
| Breaking capacity level |
M, H |
| Rated ultimate short-circuit breaking capacity Icu |
M:85kA, H:100kA |
| Rated service short-circuit breaking capacity Ics |
M:60kA, H:75kA |
Endurance
| Mechanical endurance |
2500 |
| Electrical endurance |
500 |
Dimensions
| 3P |
210x280x155mm |
| 4P |
280x280x155mm |
|
|
|
|
