Compact Fan Heater HGL 046, 400W 4A 230VAC, 45m³/h, vertical airflow, TS35 Code:
04641.0-00
Price
€120.60
/pc
(€147.13 /pc with VAT)
Availability:
In Stock
|
Weight:
1.4 kg/pc
|
Volume:
0.002 m3/pc
|
|
|
|
|
Fan Heater HGL 046 400W 220-230VAC
- Pressure clamp connectors
- Dynamic heating up
- Wide voltage range
- Temperature limting
- Energy saving
- Clip fixing
- Quick installation
These heaters are used in enclosures where damage from condensation must be prevented, or where the temperature may not fall below a minimum value. The aluminium profile heater body design has a chimney effect and distributes the heat evenly. The pressure clamp connectors save time and simplify installation.
Operating voltage |
120-240V AC/DC* (min. 110V, max. 265V) |
Heating element |
PTC resistor, self regulating and temperature limiting |
Heater body |
extruded aluminium profile, anodised |
Connection |
3 pressure clamps for stranded wire 0.5-1.5mm² (with wire end ferrule) and rigid wire 0.5- 2.5mm² |
Connection casing |
plastic according to UL94 V-0, black |
Mounting |
clip for 35mm DIN rail, EN 50022 |
Fitting position |
vertical |
Operating/Storage temperature |
-45 to +70°C (-49 to +158°F) |
Protection type/Protection class |
IP20 / I (earthed) |
Accessoires |
screw fixing, Art. No. 09024.0-00 (1 packing unit = 2 pieces) |
*Operating with voltages below 140V AC/DC reduces heating performance by approx. 10%. |
|
