Feed-through Terminal WDU 35N, 35mm² 125A 500V, beige Code:
1040400000
€7.40
/pc
(€9.18 /pc with VAT)
Manufacturer
:
|
Availability:
In Stock
|
Weight:
0.0516 kg/pc
|
Volume:
0.0001 m3/pc
|
Wholesale qty:
20pc
|
|
|
|
Feed-through terminal WDU 35N Weidmüller, beige
 |
WDU 35:
W-Series, Feed-through terminal, Rated cross-section: 35 mm2, Screw connection, Direct mounting
|
|
| |
Technical data:
|
| Dimensions and weights: |
Width: 16 mm
Height: 60 mm
Height of the lowest version: 51 mm
Depth: 50.5 mm
Weight: 52 g
Net weight: 48.104 g |
Temperatures:
|
|
Continuous operating temp., min.: |
- 50 °C |
|
Continuous operating temp., max.: |
120 °C |
Product information:
|
|
Descriptive text ordering data: |
1000 VDC rated voltage tested. 1000 V UL and CSA for use groups B and C: can be used with isolating DIN rails and when using WTW-type partitions. |
Additional technical data:
|
|
Explosion-tested version: |
No |
|
Installation advice: |
Direct mounting |
|
Number of similar terminals: |
1 |
|
Open sides: |
closed |
|
Open sides: |
Snap-on |
|
Version: |
Screw connection, for screwable cross-connection, closed |
CSA ratings data:
|
|
Certificate No. (CSA): |
12400-388 |
|
Voltage size B (CSA): |
300 V |
|
Voltage size D (CSA): |
300V |
|
Current size B (CSA): |
120 A |
|
Current size D (CSA): |
10 A |
|
Wire cross section max. (CSA): |
2 AWG |
|
Wire cross section min. (CSA): |
12 AWG |
Rated data:
|
|
Rated cross-section: |
35 mm2 |
|
Rated voltage: |
500 V |
|
Rated impulse withstand voltage: |
6 kV |
|
Rated current: |
125 A |
|
Current at maximum wires: |
150 A |
|
Standards: |
IEC 60947-7-1 |
|
Pollution severity: |
3 |
|
Surge voltage category: |
III |
Material data:
|
|
Material: |
Wemid |
|
Colour: |
Dark Beige |
|
UL 94 flammability rating: |
V-0 |
System specifications:
|
|
Product family : |
W-Series |
|
Type of connection : |
Screw connection |
|
Connection direction: |
on side |
|
Number of levels: |
1 |
|
Number of connections: |
2 |
|
No. of clamping points per level: |
2 |
|
Number of potentials per level: |
1 |
|
Levels cross-connected internally: |
No |
|
Mounting rail: |
TS 35 |
|
End cover plate required: |
No |
Classifications:
|
|
ETIM 3.0: |
EC000897 |
|
UNSPSC: |
30-21-18-11 |
|
eClass 5.1: |
27-14-11-20 |
|
eClass 6.2: |
27-14-11-20 |
|
eClass 7.1: |
27-14-11-20 |
|
Approvals:
|
 |
|
|
File description
|
File type
|
Download link
|
|
|
|
|
|
Product data sheet
|
PDF
|
Download link
|
|
|
|
|
