Thermostat LCD HT09H1 +0°..40°C 3A 24VAC week program, air sensor, Elit Code:
4742455000131
€33.10
/pc
(€41.04 /pc with VAT)
Manufacturer
:
|
Availability:
In Stock
|
Weight:
0.2819 kg/pc
|
Volume:
0.0008 m3/pc
|
|
|
|
|
Thermostat LCD HT09H1 +0°..40°C 3A 24VAC week program, air sensor
E91 weekly programming series LCD digital heating thermostat is weekly circulation, this heating room thermostat can let you set 6 periods with different setted temperature, also you can select manual mode or periods programming control mode. It is used controlling electrical heating equipments and electric control valve in water-based heating system.
The thermostat acquires the actual temperature with its built-in sensor or floor sensor, and the heating contact will close when the room temperature falls below the selected set point.
|
Detailed Product Description
- Touch screen thermostat
- Programmable room thermostat
- Electrical floor heating thermostat
- Built-in & floor sensor, floor limit sensor
- Digital thermostat
- 18 months warranty
- CE
Application
For the control of warm-water (floor) heating systems and direct electric heating systems used in Commercial buildings, Residential buildings, Light industrial buildings...
Features
- Touch-screen operating interface
- 7-day programmable function for energy-saving operation
- On/off control output for heating device
- Symbol indicator when heating is on
- Temperature limitation function for protecting the floor
- „Key-lock“ function for protecting the setted parameters (especially suitable for Public Places)
- Current room temperature displaying when the thermostat is switched-off
Technical data
Voltage:
Power consumption:
Internal sensor setting range:
Internal sensor measurement:
External sensor measurement range:
Floor sensor:
|
230VAC ± 50 / 60 Hz (24VAC Optional)
5-35± (programmable) (factory setting: 25 ° C)
0 - 40 ° C
0-90 ° (factory setting: 50°C)
Length=3M NTC B=3380 10k@25 degrees C (optional) |
|
|
|
|
|
