Image is illustrative
|
Selector Switch B2, ø22.5mm, LED 240VAC, 1-2, 1NO, 1NC 10A 250VAC, green long handle, IP40 Code:
SGB2-BK2365
€5.90
/pc
(€7.32 /pc with VAT)
Manufacturer
:
|
Availability:
In Stock
|
Weight:
0.115 kg/pc
|
|
Wholesale qty:
20pc
|
|
|
|
Illuminated LED Selector Switch 0-1 1no, green
The push button series are used in controlling circuit of AC voltage up to 660V/AC50Hz or 60Hz, and DC voltage below 400V. It is used for controlling signal and interlocking purposes. The main body of the push buttons adopts zinc alloy and high grade anti-flam plastic. The contact adopts special silver alloy in order to enjoy the benefit of high anti-electrical erosion. The signal lamp series are suitable for electrical appliances circuit of AC voltage up to 380V/50Hz, and DC voltage below 380V. It is ideal for using as indicating signals, warning signals, emergency signals, etc. Our products comply with GB/T14048.1 and IEC60947-5-1, all products are CE, ISO9001, ROHS and UL certified.
|
|
